Custom LCD Design Guide

Please fill-out the information below to complete the transaction.
The fields with an asterisk (*) are required for a successful transaction.

STANDARD/CUSTOM MODULE DESIGN GUIDE
Customer : *
Company Name : *
Address : *
Tel & Fax *
Email Address *
Reference Number : *

Standard :	MODULE LCD PANEL PART NO:
Custom :	MODULE LCD PANEL
Module Type :	TAB COB COG COF OTHER
Overall Module Size :	(W) x (H) x (T)mm
Overall Panel Size :	(W) x (H)mm
Viewing Area :	(W) x (H)mm
Fluid Type :	TN STN - FSTN
Display Type :	Positive Negative
Display Pattern :	Alphanumeric Characters x lines (Char Height ) Graphic x Dots (Size mm/Pitch mm) 7 - Segment Characters Others
Polarization :	Reflective Transflective Transmissive
Backligt : Backlight Color :	None LED (Edgelit / Array ) EL CCFL Other
Bezel :	Required Not Required
Viewing Direction :	6:00 12:00
Temperature Range :	Standard Range Wide Range Ops Temp Storage Temp
Module Power Supply Voltage :	V
LCD Driving Voltage :	V
Controller :	Included P/N Not Included
Interconnection Method :	Pinheader-Male Pinheader-Female Flex Cable Flat Cable Heat Seal Tape DIL Pins
Special Requirements :
APPLICATION :
SCHEDULE : PROTOS / SAMPLES BY:
PRODUCTION BY:
