AMP Display offers our panels with the latest Touch Panel technology options. These include
- 4-Wire and 5-Wire Resistive Touch panels
- Capacitive Touch Panels
- Interactive Touch Panels
DESCRIPTION
Touch panels are input devices that apply the film processing technologies the company has acquired while working on plastic film panels (PEP). Since the keyboards themselves are transparent, the touch panels can be placed directly on top of a display device. They are space-saving graphical input devices that can used for a wide variety of applications.
FEATURES
- Transparent touch key panels have a combination film and glass structure that offers high transmissivity and rigidity.
- The film is situated on the uppermost surface, making input possible with a light touch.
- A safe design helps prevent glass from scattering if the unit should be dropped our subjected to strong mechanical shocks.
- Transparent touch key panels can be placed directly on top of display devices.
- In line with your application needs, you have the option of choosing either an digital touch panel that has the necessary keypad patterned on it or an analog touch panel that can perform continuous recognition.
-
| ITEM |
DIGITAL TOUCH PANEL
|
ANALOG TOUCH PANEL
|
| OPERATING FORCE |
10 ~ 100g
|
100 ~ 200g
|
| TRANSPARENCY |
70%
|
80%
|
| LOGIC VOLTAGE |
5V
|
3V ~ 6.5V
|
| INSULATION RESISTANCE |
DC100V, 100
|
DC100V, 100
|
| OPERATING TEMP |
-10 C ~ +50 C
|
-10 C~ +50 C
|
| STORAGE TEMP |
-20 C~ +60 C
|
-20 C~ +60 C
|
| AVERAGE LIFE |
1,000,000 times
|
100,000 times
|
|
