GRAPHIC CONTROLLER
|
|
MFR NAME
|
TOSHIBA |
SANYO |
EPSON |
|
MFR PART NO.
|
T6963C |
LC7981 |
SED1335 |
SED1353 |
|
PIXEL COUNT:
|
128x64 ~ 240x128 Dots |
128x64 ~ 320x240 dots |
128x64~320x240 dots |
Up to 1024x768 dots Mono/16 Grayscale/ 250 colors |
|
DISPLAY CONTROL CAPACITY:
|
Graphic 64K dots |
Graphic 512K dots |
640x256 dots |
128K bytes |
|
DISPLAY DUTY:
|
1/16 ~ 1/128 |
1/1 ~ 1/256 |
1/2 ~1/256 |
1/200 ~ 1/768 |
|
SUPPLY VOLTAGE:
|
4.5V ~ 5.5V |
4.75V ~ 5.25V |
2.7V ~ 5.5V |
27V ~ 5.5V |
|
MPU INTERFACE:
|
8-bit parallel |
8-bit parallel |
8-bit parallel |
8-bit / 16 bit parallel |
|
BUILT-IN CGROM:
|
128 words |
192 words |
160 words |
- |
|
PACKAGE:
|
QFP |
QFP |
QFP |
QFP |
|
* These controllers are designed to use with LCD drivers and external RAM.
|
|
|
COMMON / SEGMENT DRIVER
|
|
MFR NAME
|
SAMSUNG
|
TOSHIBA |
|
MFR PART NO.
|
KS0107B |
KS0108B |
KS0086 |
T6A40 |
T6A39 |
|
PIXEL COUNT:
|
128X64 dots
|
128x64 ~ 320x240 dots
|
240X64 / 240X128
|
|
DUTY:
|
1/48 ~ 1/128
|
1/32 ~ 1/64
|
1/64 ~ 1/256
|
Up to 1/240
|
|
DISPLAY DUTY:
|
4.5V ~ 5.5V
|
4.5V ~ 5.5V
|
2.7V ~ 5.5V
|
4.5V ~ 5.5V
|
|
LOGIC SUPPLY VOLTAGE:
|
8V ~ 17V
|
8V ~ 17V
|
6V ~ 28V
|
8V ~ 28V
|
|
COMMON OUTPUT:
|
64
|
-
|
80
|
68
|
-
|
|
SEGMENT OUTPUT:
|
-
|
64
|
|
-
|
80
|
|
PACKAGE:
|
COB / QFP
|
COB / QFP
|
TQFP
|
QFP
|
QFP
|
|
REMARK:
|
Built-in DDRAM and Timing generator circuit could drive LCD w/o controller |
Cooperate with Controller |
Cooperate with Controller |
|
|
COMMON / SEGMENT DDRIVER (TAB TYPE)
|
| MFR NAME |
HITACHI
|
NOVATEK
|
| MFR PART NO. |
|
|
|
|
| PIXEL COUNT: |
320X240 dots
|
160x160 / 240x160 / 320x240
|
| DUTY: |
Up to 1/240
|
Up to 1/480
|
| LOGIC SUPPLY VOLTAGE: |
2.5V ~ 5.5V
|
2.5V ~ 5.5V
|
| LCD DRIVING VOLTAGE: |
2.5V ~ 5.5V
|
2.6V~ 5.5V
|
15V ~ 30V
|
| COMMON OUTPUT: |
240
|
-
|
160
|
240
|
| SEGMENT OUTPUT: |
-
|
320
|
|
|
| MPU INTERFACE: |
-
|
4-bit / 8 bit
|
4-bit / 8 bit
|
4-bit / 8 bit
|
| PACKAGE: |
TCP
|
TCP
|
TCP
|
TCP
|
| REMARK: |
HI-FAS TECHNOLOGY, EXTRA LOW POWER CONSUMPTION |
DIRECT CROSS TO SHARP DRIVER SET LH1560+LH1562 |
|
|
|
|
|
|
|
